ZKTeco inBio 260 Fingerprint RFID Access Controller

ZKTeco inBio 260 Fingerprint RFID Access Controller -08060498353

ZKTeco inBio 260 Fingerprint RFID Access Controller come in three sizes to suit project needs and reduce the cost of unused capacity. 1-door, 2-door, and 4-door models can be mixed and matched in an optimized system architecture.

Anti-Passback, First-Card Opening, Multi-Card Opening, Duress Password Entry, and Auxiliary Input/Output Linkages are built into controller firmware.

The InBio Controllers support the FR Series of readers – which transmit fingerprint templates to InBio via RS-485 for fast and accurate matching with templates stored in a database. A free Auto-discovery tool allows setting and modification of network parameters directly and easily.

InBio Fingerprint Access Controller firmware can be upgraded in the field. The Controller stores up to 3,000 fingerprint templates, 30,000 card users, and up to 100,000 events and transactions. The Controller is backed up in real-time to an onboard SD card. Data is preserved if power is lost.

The InBio continues to operate if the network connection is interrupted. Along with relay contacts for controlling door locks, easily programmable auxiliary relays can be used for additional control and interface to lights, alarms, annunciators, intrusion detection panels, or even extra locking devices or gate controllers.

Truly Internal Biometric Identification

InBio carries out the matching of fingerprints on the panels. The FR Series of readers transmit fingerprint templates to InBio vis RS485 for fast and accurate matching with templates stored in the database. Wiegand inputs are also provided for traditional RFID readers.

More than Door Control

Access additional control and interface. After programming, auxiliary relays can be functioned as lights, alarms and intrusion

detection panels. Extra locking devices or gate controllers can be accessed.

Communication

InBio controllers can be installed easily on your network and support both TCP/IP and RS-485 communication. Auto-discovery tool

allows setting and modification of network parameters directly and easily.

Options

InBio controllers come in 3 sizes to suit project needs and reduce the cost of unused capacity. 1-door, 2-door, and 4-door models

can be mixed and matched in an optimized system architecture.

Capacity

Support up to 3000 fingerprint templates, 30,000 badge users and store up to 10,000 events and transactions. Data is preserved if power is lost.

Controller continues to operate if network connection is interrupted.

Advanced Access Control Built-In

Anti-Passback, First-Card Opening, Multi-Card Opening, Duress Password Entry, and Auxilary input/output linkages are built into

controller firmware.

For Software Developers

Free SDK is available for integrators and OEM’s to integrate the InBio controller with their or existing security or personnel management

applications. Upon request, ZK can customize InBio firmware to meet any customer requirements.

ZKTeco inBio 260 Fingerprint RFID Access Controller Key Features:

• Number of doors controller – 2 Door
• Numbers of readers
• supported – 8(4 RS-485 Reader,4 26-bit wiegand reader)
• Types of readers supported – 26-bit Wiegand and RS485 FR Series Reader
• Number of Inputs – 6( 2 Exit Devices, 2 Door Status, 2 AUX)
• Number of Outputs – 4 (2-Form C Relay for Lock and 2-Form C Relay for Aux Output)
• Cardholders Capacity – 30,000
• Fingerprint Capacity – 3,000
• Log Events Capacity – 100,000
• Communication – TCP/IP and RS-485
• Package Dimension – 350(L)×90(H)×300(W)mm
• Package Weight – 3.6KG
• CPU – 32-bit 400MHz CPU
• RAM – 32M
• FLASH MEMORY – 128M
• POWER – 9.6V-14.4V DC
• OPERATING TEMP – 0-45 °C
• Operating Humidity – 20% T0 80%
